Kia Sportage: Rear Door / Rear Door Belt Inside Weatherstrip Repair procedures

Kia Sportage QL (2015-2025) Service Manual / Body (Interior and Exterior) / Rear Door / Rear Door Belt Inside Weatherstrip Repair procedures

Replacement

1.	Remove the rear door trim. (Refer to Rear Door - "Rear Door Trim")

2.	Remove the rear door belt outside weatherstrip (A) after loosening the mounting screw.

Install in the reverse order of removal.

Replace any damaged clips.
