Kia Sportage: Automatic Transaxle Control System / Input Speed Sensor Description and operation

Kia Sportage QL (2015-2026) Service Manual / Automatic Transaxle System / Automatic Transaxle Control System / Input Speed Sensor Description and operation

Description

•	Input speed sensor uses an electric current type hall sensor in which the current is changed by the magnetic variation.

•	Input speed sensor and output speed sensor are integrated and installed in the transaxle.

Functions

•	Measures the rate of rotation of the input shaft inside the transaxle and delivers the readings to the TCM.

•	The sensor provides critical input data used in feedback control, torque converter clutch control, gear setting control, line pressure control, clutch activation pressure control, and sensor fault analysis.

Input Speed Sensor Specifications

Specification Item Specification Type Hall effect sensor Operating condition (°C)°F (-40 to 150) ...

Input Speed Sensor Schematic diagrams

Circuit Diagram ...
