Signal Waveform
The three waveforms below are taken from the #1 and #4 injectors. The top waveform
is from the high side (feed side) of the #1 and #4 injectors, while the middle
waveform is from the low side (ground side) of the #1 injector and the bottom
waveform is from th ...
Specification
Item
Specification
Type
Hall effect sensor
Operating condition (°C)°F
(-40 to 150) -40 to 302
Output voltage (V)
High : 1.18 - 1.68
Low ...
