Kia Sportage: Warning Messages / Icy Road Warning Light (if equipped)

Kia Sportage QL (2015-2021) Owners Manual / Features of your vehicle / Trip modes (Trip computer) / Warning Messages / Icy Road Warning Light (if equipped)

This warning light is to warn the driver the road may be icy.

When the following conditions occur, the warning light (including Outside Temperature Gauge) blinks 5 times and then illuminates, and also warning chime sounds once.

- The temperature on the Outside Temperature Gauge is below approximately 40°F (4°C).

✽ NOTICE

If the icy road warning light appears while driving, you should drive more attentively and safely refraining from over-speeding, rapid acceleration, sudden braking or sharp turning, etc.

Sunroof Open (if equipped)

The warning message illuminates if you turn off the engine and then open the driver's door when the sunroof is open. ...

Align steering wheel (if equipped)

This warning message illuminates if you start the engine when the steering wheel is turned to more than 90 degrees to the left or right. It means that you should turn the steering wheel and ...
